This is a small carry caddy styled after an old wooden soda crate: a boxy tote with a raised center divider that doubles as a handle. It's a one-afternoon scrap project — the whole thing comes out of a 1x8 and a bit of 1x6 — and it's a great use for reclaimed or pallet wood, where a little age and character actually improves the look.
The only shaped part is the handle board. Drill two 1" holes with a hole saw where the ends of the hand-hole go, then jigsaw out the waste between them to make a comfortable grip. Clip the top corners at 45° and round the top edge with the jigsaw for that classic crate silhouette. Everything else is straight cuts and butt joints.
Assembly is fast: attach the side pieces to the central handle board, then the remaining sides, then tack the bottom on. Glue plus 2" finish nails is all it needs — a brad nailer makes it go very quickly. The source entry didn't list tools, so this build infers them from the steps (a hole saw and jigsaw for the handle, a nailer for assembly). Leave the reclaimed wood as-is for patina, or clean it up and finish. It makes a charming gift filled with something.
| Item | Qty |
|---|---|
| 1x8, 2 ftHandle/divider board — reclaimed or pallet wood is ideal. | 1 each |
| 1x6, 4 ftSides and bottom. | 1 each |
| Finish nails, 2 in | 1 box |
| Wood glue | 1 bottle |
| FinishOptional — leave reclaimed wood raw for patina. | 1 each |
Overall cost: $. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Handle / center divider1x8Two 1" holes + jigsaw cut-out for the grip; top corners clipped 45° and rounded. | 1 | 3/4" × 7 1/4" × 9 1/2" |
| Long sides1x6 | 4 | 3/4" × 5 1/2" × 11" |
| Bottom / end pieces1x6 | 2 | 3/4" × 5 1/2" × 9 1/2" |
| End pieces1x6 | 2 | 3/4" × 5 1/2" × 4 3/8" |
Buy 2 boards at 8 ft.
1 board
1 board
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Cut the handle from the 1x8. Drill two 1" holes with a hole saw where the ends of the hand-hole will be, then jigsaw out the waste between them to make the grip. Clip the top corners at 45° off square and round the top edge with the jigsaw for the crate look.
Attach the side pieces to the handle board with glue and 2" finish nails — a nailer makes this go fast. The handle board is the center spine, so the sides register off it.
Attach the remaining side pieces the same way, glue and 2" finish nails, to build out the box on both sides of the handle.
Tack the bottom on with finish nails and glue to close the caddy. Soften any sharp edges. Leave reclaimed wood raw for patina, or clean it up and finish.
