The whole stand is just two identical 45°-angled frames joined together, which is what makes this one of the fastest builds in the catalog — get the 45° angle right once (a scrap block cut to that angle, or a speed square, both work as a guide) and every joint in both frames repeats the same cut. The two frames lean the buckets back at a display angle rather than standing them upright, which is the entire trick behind why loose buckets or baskets sit securely on it without any hardware holding them in place — gravity and the lean do the work.
The cross support, scribed to fit after the frames are joined rather than cut to a fixed measurement up front, is what keeps the stand rigid side to side. Scribing it in place (tracing the actual angle off the assembled frame) is more reliable than trusting a calculated angle, since small variations in how square each frame came out will change that angle slightly.
| Item | Qty |
|---|---|
| Pine, 1x3, 8 ft | 6 each |
| Pocket hole screws, 1-1/4", or 2" self-tapping screws | 1 box |
| Brad nails or staples, 1-1/4" | 1 box |
| Wood glue | 2 oz |
| Buckets or basketsNot included in the cost estimate — pick sizes that fit your own frame spacing. | 9 each |
Overall cost: $. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Frame boardsPine 1x3 | 10 | 3/4" × 2 1/2" × 35" |
| Frame cross bracesPine 1x3 | 4 | 3/4" × 2 1/2" × 14" |
| Center cross supportPine 1x3Scribed to fit after the frames are assembled, not cut to a fixed length up front. | 2 | 3/4" × 2 1/2" × 35" |
Buy 6 boards at 8 ft.
6 boards
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Build two identical A-frames from the frame boards and cross braces. Use a scrap block cut at 45°, or a speed square, to guide placing the boards at the correct angle. Attach with 1-1/4" pocket hole screws or 2" self-tapping screws, gluing every joint.
Attach the two frames together with 1-1/4" nails, staples, or screws and glue. Lay a scrap board over the sides, trace the actual angle where it crosses, cut to that scribed line, and attach for additional side-to-side rigidity.
Set your buckets or baskets into the angled frames — the lean is what holds them in place with no extra hardware.
