A simple, good-looking decorative tray — the kind that holds a candle and a couple of books on a coffee table, or corrals clutter on a counter. Three 1x4 boards glued edge to edge make the bottom, framed with 1x3 sides standing proud to form a lip. Add handles if you want to carry it.
The only technique is the glue-up: join the three 1x4s edge to edge and let them fully set before you do anything else, because a tray bottom that hasn't cured will spring apart when you nail the sides on. Then measure the actual combined width of your glued panel and cut the end trim to match — nominal math won't be exact once three boards are joined.
Stain suits it better than paint, and a couple of coats of a wipe-on finish protect it from candle wax and coffee rings. Under an hour of work plus drying time, and it makes a solid gift.
| Item | Qty |
|---|---|
| 1x4, 4 ftBottom boards. | 1 each |
| 1x3, 5 ftTrim sides and ends. | 1 each |
| Brad nails, 1-1/4" | 24 each |
| Wood glue | 2 oz |
| Wood filler | 1 each |
| Wood stain | 1 each |
| HandlesOptional. | 2 each |
Overall cost: $. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Bottom boards1x4 | 3 | 3/4" × 3 1/2" × 15 3/4" |
| End trim1x3Cut to match your glued panel width (~10-1/2"). | 2 | 3/4" × 2 1/2" × 10 1/2" |
| Side trim1x3Cut to fit. | 2 | 3/4" × 2 1/2" × 17 1/2" |
Buy 2 boards at 8 ft.
1 board
1 board
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Glue the three 1x4 boards edge to edge and let them fully set — don't rush this, a bottom that hasn't cured springs apart when you nail into it. Once set, measure the combined width of the glued panel, cut the 1x3 end boards to match, and attach with 1-1/4" brad nails and glue.
Measure and cut the side pieces to fit and nail and glue them to the sides, forming the tray lip. Fill nail holes, sand, and stain — a couple of coats of a wipe-on finish protect it from wax and rings. Add handles if you want to carry it.
