The build order here solves a real fitting problem: the 2x2 under-supports are measured and cut AFTER the tabletop boards are laid out, not before, because the actual assembled width of six 1x6 boards edge to edge varies slightly from a purely calculated number. Cutting the supports to match the real width avoids a support that's a hair too long or short relative to the top it's supposed to carry.
The side aprons are deliberately sized to overhang the 2x2 supports on the underside — the plan is explicit that this is fine, not an error to true up. It's what lets the aprons sit flush with the top and ends on the visible faces, which is where flushness actually matters for how the table looks.
| Item | Qty |
|---|---|
| Pine, 2x4, 8 ft | 3 each |
| Pine, 1x6, 8 ft | 2 each |
| Pine, 2x2, 8 ft | 2 each |
| Wood screws, 3" | 12 each |
| Wood screws, 2-3/4", self-tapping | 40 each |
| Wood screws, 2", self-tapping | 36 each |
Overall cost: $. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Under-tabletop supportsPine 2x2Measure the assembled tabletop width and cut to match, rather than trusting this number exactly. | 4 | 1 1/2" × 1 1/2" × 33" |
| Tabletop boardsPine 1x6 | 6 | 3/4" × 5 1/2" × 31 3/4" |
| Side apronsPine 2x4 | 2 | 1 1/2" × 3 1/2" × 31 3/4" |
| Leg-side apronsPine 2x4Measure and cut to fit. | 2 | 1 1/2" × 3 1/2" × 29" |
| LegsPine 2x4 | 4 | 1 1/2" × 3 1/2" × 30" |
Buy 8 boards at 8 ft.
3 boards
2 boards
3 boards
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Lay the tabletop boards on a flat surface, edge to edge, and measure the actual assembled width. Cut the under-tabletop supports to match this real measurement. Glue and screw the supports to the underside with the shorter screws, keeping outside edges flush and checking for square.
Measure and cut the side aprons from 2x4s. Attach so they're flush with the top and ends of the tabletop assembly — they'll overhang the 2x2 supports on the underside, which is expected. Use the longer screws.
Attach the legs with the longer screws, using a square to confirm each leg sits square to the table as you attach it — two screws through the apron, then more screws driven from the inside through the 2x2 supports.
Glue and screw the leg-side aprons on with the longer screws to complete the base.
Sand every surface smooth and apply your finish of choice.
