This console pares a console table down to its barest structural minimum: a top, two solid 1x12 legs, a bottom shelf, and a single inset 1x10 back board — four boards, no aprons, no separate stretchers. Attach the top to the legs first with either brad nails and glue or pocket holes, a choice the plan leaves genuinely open since either works fine at this scale.
The back board is the one piece worth some care: it sets in flush between the two legs rather than spanning across their outside faces, which is what gives the piece its clean, inset look from the front. This inset back board is doing real structural work despite its plain appearance — it's the only piece tying the two legs together besides the top and shelf, so getting it snug against both legs matters more than it looks like it should on a four-board table.
The bottom shelf attaches to the sides and the back board last, closing up the whole structure. Because there's no separate apron or stretcher system, keeping every joint square as you go is what keeps the finished piece from racking — there's no second chance to add bracing after the fact without it showing.
| Item | Qty |
|---|---|
| 1x12, 12 ft (pine or whitewood) | 1 each |
| 1x10, 4 ft (pine or whitewood) | 1 each |
| Brad nails, 1-1/4", or pocket hole screws, 1-1/4" | 40 each |
| Wood glue | 3 oz |
| Primer and paint, or stain and poly | 1 set |
Overall cost: $$. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Legs1x12, 12 ft (pine or whitewood) | 2 | 3/4" × 11 1/4" × 29 1/4" |
| Top1x12, 12 ft (pine or whitewood) | 1 | 3/4" × 11 1/4" × 48" |
| Shelf1x12, 12 ft (pine or whitewood) | 1 | 3/4" × 11 1/4" × 46 1/2" |
| Back panel1x10, 4 ft (pine or whitewood) | 1 | 3/4" × 9 1/4" × 46 1/2" |
Buy 3 boards at 8 ft.
2 boards
1 board
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Attach the top to the two legs with 1-1/4" brad nails and glue, or with pocket holes and 1-1/4" pocket hole screws.
Attach the 1x10 back panel inset between the two legs.
Attach the bottom shelf to the legs and the back panel.
Sand all surfaces and apply primer and paint, or stain and poly.
