This is the fridge that completes a play kitchen — a tall narrow box with two doors, a small freezer up top over a taller fridge below, sized to sit beside a play stove and sink. It's just a plywood-free box of 1x12 boards, which keeps it solid and paintable, and it holds up to years of small-child abuse.
The build is honest and quick: nail and glue the box (the source builder used a pneumatic nailer and glue and reports it's still going strong years later), add the back nailing into the internal shelves for rigidity, then hang the two doors. The doors are the only place to fuss — euro-style inset hinges are concealed, cheap, and easy to mount, and they let the doors sit flush and swing cleanly. Magnetic clasps keep them shut so the play food stays put.
Because it's a toy, round over the door edges and corners, and use a durable, child-safe finish. The door boards may need trimming to fit your actual openings — measure before final cut.
| Item | Qty |
|---|---|
| 1x12, 12 ftSides, tops/bottoms, and doors. | 12 linear ft |
| 1x10, 12"Fridge shelf. | 1 each |
| 1x2, 2 ftBottom trim. | 1 each |
| 1/4" plywood, 12" x 36"Back. | 1 each |
| HingesEuro-style inset concealed hinges. | 2 set |
| Magnetic clasps | 2 each |
| Handles | 2 each |
| Brad nails, 1-1/4" | 1 box |
| Wood glue | 6 oz |
| Child-safe finishDurable and rated safe once cured. | 1 kit |
Overall cost: $$. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Sides1x12 | 2 | 3/4" × 11 1/4" × 36" |
| Bottom trim1x2 | 2 | 3/4" × 1 1/2" × 11 1/2" |
| Tops / bottoms1x12 | 3 | 3/4" × 11 1/4" × 11 1/2" |
| Fridge shelf1x10 | 1 | 3/4" × 9 1/4" × 11 1/2" |
| Back1/4" plywood | 1 | 1/4" × 13" × 36" |
| Freezer door1x12May need trimming to fit. | 1 | 3/4" × 11 1/4" × 12" |
| Fridge door1x12May need trimming to fit. | 1 | 3/4" × 11 1/4" × 20 1/4" |
Buy 5 boards at 8 ft.
2 boards
1 board
1 board
1 board
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Build the box as shown — sides, top, bottom, the middle divider that splits freezer from fridge, and the interior shelf. Use finish nails and glue at every joint. Keep it square.
Add the 1/4" plywood back, nailing into the interior shelves as well as the sides for rigidity. Shorter 1-1/4" nails are fine on the back.
Hang the two doors on euro-style inset concealed hinges — cheap, easy to mount, and they let the doors sit flush. Add the magnetic clasps to keep them shut and the handles. Trim the door boards first if they don't fit your openings. Round every edge, then finish with a durable child-safe finish.
