This is a shallow wall organizer: a long, low box divided into nine angled cubbies, perfect for sorting mail, holding papers, or giving each kid a numbered daily slot. It's a quick 1x3-and-1x2 build with one clever assembly aid — a scrap spacer block that guarantees every bay comes out the same width.
The dividers are cut with a 45° angle on one end (long-point measurement), so the fronts of the cubbies are open and angled for easy access — you can see and grab what's in each slot. The trick to even spacing is cutting a scrap 1x3 to exactly 4" and using it as a gauge: butt each divider against the block as you fasten it, and all nine bays land at 4" without measuring each one.
Assembly is three passes: dividers to the bottom board, then the back boards, then the front boards, using the 4" block throughout. One practical note from the build: as you fasten near the top, switch from 2" to 1-1/4" nails, because the 45° miter leaves less material and a 2" nail won't have clearance. And don't forget glue. Number the cubbies with paint, vinyl, or little tags, and mount it to the wall studs. A battery brad nailer that needs a hard push can make the divider step fiddly — marking, predrilling, and screwing is a fine alternative.
| Item | Qty |
|---|---|
| 1x3, 8 ftBottom, dividers, front and back rails. | 3 each |
| 1x2, 8 ftTrim rails. | 1 each |
| Brad nails, 1-1/4 in and 2 in | 1 box |
| Wood glue | 1 bottle |
| Paint or finish and numbers | 1 each |
Overall cost: $. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Back/front long rails1x3 | 4 | 3/4" × 2 1/2" × 38 3/4" |
| Long trim rails1x2 | 2 | 3/4" × 1 1/2" × 38 3/4" |
| Dividers1x3One end cut at 45°, long-point measurement. | 9 | 3/4" × 2 1/2" × 7 1/4" |
Buy 4 boards at 8 ft.
3 boards
1 board
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Cut a scrap 1x3 to 4" and use it as a spacer block. Nail the nine dividers to the bottom board, spaced 4" apart with the block. If your nailer struggles (a battery nailer that needs a hard push can be awkward here), mark the holes, predrill, and attach with screws instead. Don't forget glue.
Keeping the 4" spacing at the top with your block, attach the back boards to the dividers and bottom with 2" finish nails and glue. As you near the top, switch to 1-1/4" nails — the 45° miter doesn't leave enough material for a 2" nail to clear.
Nail the front boards on, again using the 4" block as a guide so every bay stays even. Sand smooth, finish or paint, and add numbers (paint, vinyl, or tags). Mount to the wall studs, level.
