This captain's bed builds its storage from three genuinely separate cubby boxes — one across the end and two running along the sides — rather than three identical joined modules, and skips drawers entirely in favor of open shelving accessed from the top. Build the end cubby first, then the two side cubbies, each one its own square box before anything gets tied together.
Have the lumber yard rip your 1/4" plywood into 15" strips before you leave the store — the plan's own tip, since a single ripped sheet is easier to haul in a car and only needs one crosscut per back panel afterward rather than a full sheet's worth of ripping at home. Attach the back panels to each cubby with nails and glue, making sure to nail into the center partition as well as the outer sides.
Once all three cubbies have their backs on, trim goes on the side cubbies, and cleats attach to the backs of the side cubbies only — the end cubby doesn't get cleats, since the mattress platform's slats rest on the side cubby cleats and simply attach to the end cubby directly. Slats are deliberately not glued down, laid on top of the cleats and screwed only — this is explicit in the plan, since it keeps the whole bed easy to disassemble for moving, unlike a glued platform that would need to be broken apart.
| Item | Qty |
|---|---|
| 1x12, 8 ft | 6 each |
| 1/4" plywood, ripped to 15 in strips, full sheet | 1 each |
| 1x2, 8 ft | 6 each |
| 1x3, 8 ft | 5 each |
| Wood screws, 2" | 60 each |
| Wood screws, 1-1/4" | 60 each |
| Finish nails, 1-1/4" and 2" | 100 each |
| Wood glue | 6 oz |
| Wood filler | 3 oz |
| Primer and paint, or stain and poly | 1 set |
Overall cost: $$$$. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Cubby sides1x12, 8 ft | 6 | 3/4" × 11 1/4" × 15" |
| Cubby dividers1x12, 8 ft | 3 | 3/4" × 11 1/4" × 12 3/4" |
| End cubby top/bottom1x12, 8 ft | 2 | 3/4" × 11 1/4" × 54" |
| Side cubby top/bottom1x12, 8 ft | 4 | 3/4" × 11 1/4" × 62" |
| Vertical trim1x2, 8 ft | 6 | 3/4" × 1 1/2" × 12" |
| End top/bottom trim1x2, 8 ft | 2 | 3/4" × 1 1/2" × 55 1/2" |
| Side top/bottom trim1x2, 8 ft | 4 | 3/4" × 1 1/2" × 63 1/2" |
| Center support cleats1x3, 8 ft | 2 | 3/4" × 2 1/2" × 63 1/2" |
| Center support slats1x3, 8 ft | 11 | 3/4" × 2 1/2" × 30 1/2" |
| Cubby backs1/4" plywood, ripped to 15 in strips, full sheetCut to fit each cubby's back opening. | 3 | 1/4" × 15" × 96" |
Some parts are longer than a 8 ft board, so there is no honest board count to show here. Open the board plan to pick a longer stock length — it names every part that does not fit.
6 boards
5 boards
6 boards
0 boards
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Build one end cubby box from the sides, divider, and top/bottom.
Build two side cubby boxes the same way.
Cut the 1/4" plywood backs to fit each cubby (have the sheet ripped into 15" strips at the lumber yard first). Attach with 1-1/4" nails and glue, nailing into the center partition as well as the outer sides.
Attach the vertical, top, and bottom trim pieces to all three cubbies with 2" nails and glue.
Use 2" screws and glue to fasten the center support cleats to the backs of the two side cubbies only.
Lay the slats on top of the cleats and screw in place with 1-1/4" screws, without glue, so the bed can be disassembled easily. Also screw the end cubby to the slats.
Position the end cubby and two side cubbies together with the slat platform between them to form the complete bed frame.
Fill any screw holes with wood filler, sand all surfaces, and apply primer and paint, or stain and poly.
