The angled dividers do double duty as both the bin's structure and its ventilation — cutting them at 15° instead of square opens a gap between the front slats that lets air move through, which is what keeps stored produce from sweating and rotting early. Cut one divider first and use it as a pattern for the rest, rather than resetting your saw angle four separate times; that's both faster and guarantees all four come out identical.
The feet need slightly more than 3/4" of clearance on the outside for a reason worth keeping: it lets two or more bins stack on top of each other without the upper bin's feet interfering with the lower bin's front slats. Use only food-safe finish, since this sits in direct contact with produce you'll eat.
| Item | Qty |
|---|---|
| Pine, 1x8, 6 ft |
| 1 each |
| Pine, 1x4, 8 ft | 1 each |
| Brad nails, 1-1/4" | 1 box |
| Wood glue | 2 oz |
| Food-safe stain or finish | 1 each |
| Self-adhesive furniture feet padsProtects the countertop under each foot. | 4 each |
Overall cost: $. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| FeetPine 1x8Cut these first. | 2 | 3/4" × 7 1/4" × 1" |
| Angled dividersPine 1x8Longest point measurement, one end cut at 15° off square. Cut one first and use it as a pattern for the rest. | 4 | 3/4" × 7 1/4" × 9 3/4" |
| BottomPine 1x8 | 1 | 3/4" × 7 1/4" × 31 1/2" |
| Front and back panelsPine 1x4 | 3 | 3/4" × 3 1/2" × 31 1/2" |
Buy 2 boards at 8 ft.
1 board
1 board
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Set your saw to 15° off square and cut one divider with the long point at 9-3/4". Reset the saw to square (0°) and cut the second divider, using the first one's angled edge as your reference. Repeat for the remaining two dividers. Then set the saw to 30° off square, mark the longer corner as shown in the diagram, and cut it off.
Attach the 1x8 bottom to the dividers with 1-1/4" brad nails and wood glue.
Attach the front 1x4 panel with 1-1/4" brad nails and wood glue.
Attach the two back 1x4 panels the same way, with 1-1/4" brad nails and wood glue.
Attach the feet to the bottom, leaving slightly more than 3/4" of clearance on the outside — that extra margin is what lets multiple bins stack. Sand everything smooth, finish with a food-safe stain or leave bare, and add the self-adhesive pads to the bottom of the feet.
