Designed around stud-length lumber specifically so a venue or planner building several of these at once can buy studs (already cut to a common length) instead of full boards, minimizing both waste and cutting time per bench. That's the whole reason for the design: fast, repeatable, and cheap enough that building ten of them for a wedding doesn't feel like ten separate furniture projects.
Angling a few of the leg screws rather than driving them all straight in is a small trick worth remembering — it resists the leg racking sideways under load in a way that a straight-in screw alone doesn't, since the angled screw is working somewhat in tension against that specific direction of movement. The tie-in board between the legs at the bottom is what actually keeps a bench like this from wobbling once people are sitting and standing on it all day; don't treat it as optional even though the bench will stand without it.
| Item | Qty |
|---|---|
| Pine, 2x4, stud length (92-5/8") | 2 each |
| Pine, 2x6, stud length (92-5/8") | 2 each |
| Pine, 2x4, 8 ftAbout 12 ft of 2x4 total needed for the legs and bracing, with some left over. | 2 each |
| Exterior self-tapping wood screws, 2-3/4" | 1 box |
Overall cost: $$. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Seat top boardsPine | 2 | 1 1/2" × 3 1/2" × 92 5/8" |
| Seat support boardsPine | 2 | 1 1/2" × 5 1/2" × 92 5/8" |
| LegsPine | 2 | 1 1/2" × 3 1/2" × 14 1/2" |
| Leg bracesPine | 4 | 1 1/2" × 3 1/2" × 16 1/2" |
| Leg cross bracesPine | 2 | 1 1/2" × 3 1/2" × 8 1/2" |
| Tie-in boardsPineBoth ends cut at 45° off square, ends parallel — long point to short point measurement. | 2 | 1 1/2" × 3 1/2" × 17" |
Buy 6 boards at 8 ft.
2 boards
4 boards
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Screw the 2x4 top boards to the 2x6 support boards, spacing screws every 8"–12" along the length.
Screw the end boards to both ends of the 2x4-and-2x6 assembly.
Screw the legs to the inside of the outer frame. Angle a few screws in on each leg rather than driving them all straight — this resists the leg racking sideways under load.
Add a tie-in board between the two legs near the bottom, leaving about a 3" gap below it. This is what keeps the bench from wobbling once it's loaded with people sitting and standing — don't skip it.
