Most backyard coops look like a shed had a rummage sale. This one is deliberately modern — a single 5° slant roof of off-the-shelf tin, clean cedar picket siding, and proportions that survive being visible from the kitchen window. Underneath the looks it's a thoroughly practical two-level coop: wire-wrapped run below, sided roost above, nesting box from plywood scraps.
The plan is full of the builder's own field corrections, which are the best parts. The floor is cut 1/2" small and NOT screwed down, so it lifts out for cleaning, with a lip added at the back to keep bedding from avalanching when the door opens. The back door was upgraded to full-height after living with a smaller one, because cleaning access is the difference between a coop you maintain and one you resent. And the paint tip is underlined for a reason: finish the frame interiors BEFORE stapling on the chicken wire — painting through mesh is misery.
The picket siding uses a smart taper method: cut the first picket at 5° to match the roof slope, then use each piece's short point to measure the next, working down the slope and eventually cutting from offcuts. Use hardware cloth rather than chicken wire if raccoons are serious in your area — wire keeps chickens in; cloth keeps predators out.
| Item | Qty |
|---|---|
| 2x4, 10 ftThe starred long cuts come from these — cut the longest pieces first. | 6 each |
| 2x4, 8 ft | 8 each |
| 2x2, 8 ftFloor cleats and interior trim. | 2 each |
| Cedar fence picket, 5-1/2" x 72"All the siding. (1/2" exterior plywood substitutes, but the source warns: two full sheets and a lot of waste.) | 15 each |
| Exterior plywood, 3/4", 4x8 sheetFloor and nesting box. | 1 each |
| Tin roof panel, 37-1/2" x 8 ftThe design is dimensioned around this stock sheet — buy it first and confirm the size. | 1 each |
| Metal roofing screwsWith sealing washers. | 16 each |
| Chicken wire or hardware cloth, 36" wideHardware cloth costs more and is worth it — raccoons open chicken wire. | 20 linear ft |
| Chicken wire or hardware cloth, 24" wide | 15 linear ft |
| Staples, 1/2" | 1 box |
| Exterior pocket hole screws, 2-1/2" | 100 each |
| Self-tapping screws, 1-1/4" to 1-3/4", star driveSiding. | 120 each |
| Self-tapping screws, #9 x 2-1/2", star drive | 20 each |
| Exterior hingesTwo sets — front and back doors. | 4 each |
| LatchesRaccoon-resistant style. | 2 each |
| 1x3, 8 ftNesting box lip. | 1 each |
Overall cost: $$$. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Side frame top railsBoth ends 5° off square, parallel, long point to short point — the roof slope. | 2 | 1 1/2" × 3 1/2" × 94 1/2" |
| Side frame uprights, tallOne end 5° off square, long point measurement. From the 10-footers. | 2 | 1 1/2" × 3 1/2" × 61" |
| Side frame uprights, middleOne end 5°, long point. From the 10-footers. | 2 | 1 1/2" × 3 1/2" × 58 1/4" |
| Side frame uprights, shortOne end 5°, long point. From the 10-footers. | 2 | 1 1/2" × 3 1/2" × 53 1/4" |
| Side frame bottom rails | 2 | 1 1/2" × 3 1/2" × 91 1/8" |
| Side frame mid railsFrom the 10-footers. | 2 | 1 1/2" × 3 1/2" × 52 1/2" |
| Cross members | 7 | 1 1/2" × 3 1/2" × 33" |
| Floor cleats2x2 | 2 | 1 1/2" × 1 1/2" × 55" |
| Interior trim2x2 | 2 | 1 1/2" × 1 1/2" × 34 1/8" |
| Floor3/4" plywoodThen trimmed ~1/2" small to lift out — see the steps. | 1 | 3/4" × 32" × 54 1/2" |
| Front door stilesFrom the 10-footers. | 2 | 1 1/2" × 3 1/2" × 64" |
| Back door stilesReduced from the drawn 56-3/8" for swing clearance. From the 10-footers. | 2 | 1 1/2" × 3 1/2" × 56" |
| Door rails | 5 | 1 1/2" × 3 1/2" × 29" |
| Nesting box floor3/4" plywood | 1 | 3/4" × 13" × 31 1/2" |
| Nesting box dividers3/4" plywood | 3 | 3/4" × 6" × 13" |
| Nesting box lip1x3 | 1 | 3/4" × 2 1/2" × 31 1/2" |
Buy 22 boards at 8 ft.
16 boards
Lay out the first side frame (sloped top rail, three graduated uprights, bottom and mid rails), mark and drill the 1-1/2" pocket holes, and assemble with 2-1/2" exterior pocket screws. Build the second frame IN MIRROR — the frames face each other.
Do the builder's regret-tip now: paint or seal the frame interiors before any wire goes on. Painting through stapled mesh is the worst hour of the whole project.
Staple chicken wire or hardware cloth to the frame insides. Trim the excess and FOLD the cut edges over before the final staples — trimmed wire ends are needle-sharp, and both you and the birds will find them otherwise.
Screw the 2x2 floor cleats to the frame insides with the 2-1/2" screws — these carry the removable roost floor.
Cut the first cedar picket with its top at 5° (long-point measurement) and attach to the side wall inside face, flush with the 2x2 top, leaving at least 1-1/2" of frame exposed above. Two of the shorter screws per joint.
Measure the SHORT point of the picket you just installed — that's the LONG point of the next one. Cut, install, repeat down the slope. The first few cuts need fresh pickets; before long the offcuts are supplying the pieces, which is the method's whole economy.
Drill two 1-1/2" pocket holes in each end of the 33" 2x4s and attach them to one side frame, then flip the assembly onto the second frame and attach. The coop becomes three-dimensional here — a second pair of hands saves a lot of awkward propping.
(The source left one bottom-end 2x4 off for easier cleaning access — shown in photos, optional.)
Add the 2x2 interior trim, then side the interior wall with pickets and the shorter screws, saving offcuts for the doors. The upper opening this creates is both ventilation and the birds' door to the run — it stays open because the run below is enclosed.
Cut the plywood floor to fit its opening MINUS about 1/2" all around, set it on the cleats, and do not screw it down. A floor you can lift out is a coop you can actually clean. Add a lip strip at the back edge — the source's own improvement — so bedding doesn't pour out when the door opens.
Pocket-hole the front door frame together, staple wire to its back, and hang it with hinges and a latch. Check the swing clears the siding before final hinge screws.
Build the back door — pickets over the upper portion, wire over the lower — and hang it. This full-height door is the source's post-build upgrade: it makes the lower level cleanable without crawling, which is the feature you'll thank yourself for monthly.
Slide the 37-1/2" x 8 ft tin sheet onto the sloped frame tops and fasten with the metal roofing screws into the 2x4s. The whole coop was dimensioned around this off-the-shelf panel — no cutting, no seams, no leaks to create.
Assemble the nesting box from the plywood pieces — floor, three dividers, 1x3 lip — with pocket holes or 2-1/2" screws, and install it in the roost. Bed it, introduce the flock, and accept that the coop now looks better than the shed.
No reviews yet
Sign in to review this plan or share your build.
No reviews yet. Be the first to build this.
2 boards
1 board
1 board
1 board
1 board
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
