This is the simplest bench in the catalog on purpose — a 2x4 frame, four 2x4 legs, and twelve 1x4 slats laid across the top with even gaps. It's sized and priced to sit alongside a simple outdoor dining table without becoming a bigger project than the table itself.
Build the frame first and check it for square before the legs go on, by measuring both diagonals and adjusting until they match — a frame that's slightly off-square at this stage stays off-square for the life of the bench. Attach the legs to the square frame, then lay the slats on top with a consistent 1/2" gap between them, which is enough for water to drain through without looking sparse.
The shopping list here is written per single bench — for a table that seats more people, just build as many benches as you need from the same cut list.
| Item | Qty |
|---|
| 2x4, 8 ft | 2 each |
| 1x4, 8 ft | 2 each |
| Exterior screws, 2-1/2", star drive | 20 each |
| Exterior screws, 1-1/2", star drive | 50 each |
| Exterior stain or paint | 1 qt |
Overall cost: $. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Frame ends2x4 | 2 | 1 1/2" × 3 1/2" × 12 7/8" |
| Frame sides2x4 | 2 | 1 1/2" × 3 1/2" × 44 1/2" |
| Legs2x4 | 4 | 1 1/2" × 3 1/2" × 17 1/4" |
| Bench slats1x4 | 12 | 3/4" × 3 1/2" × 15 7/8" |
Buy 6 boards at 8 ft.
3 boards
3 boards
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Build the basic 2x4 frame with the frame ends and sides and the longer 2-1/2" screws. Check the frame for square by measuring both diagonals and adjusting until they match before moving on.
Screw the four legs to the square frame with the longer screws.
Lay the slats out on top of the frame with a 1/2" gap between each one and screw down with the shorter screws. Sand and finish before use outdoors.
