This daybed skips the usual box-and-panel construction and instead builds the whole headboard and footboard out of nine identical small rectangle frames, joined into three columns of three. It's a look borrowed straight from window-pane furniture, and the trick to pulling it off is building the frames as a batch — cut every rectangle side, joiner, and cross-piece before you assemble a single one, so all nine come out exactly the same size.
Structurally, the rectangle grid is decorative; the actual bed strength comes from the 2x3 aprons and 2x2 legs it's screwed to. Build the H-shaped leg-and-apron frames first and get those square and solid, then treat the rectangle grid as infill you attach to a structure that's already doing the real work. Pocket holes throughout make this realistic without a router or dado stack — the only real skill is patience with nine identical small assemblies.
| Item | Qty |
|---|---|
| 1x2 board, 8 ftAll 63 pieces of the rectangle grid come from this stock — cut every piece before assembling anything. | 7 each |
| 2x2 board, 8 ftLegs, back top rail, and cleats. | 6 each |
| 2x3 board, 8 ftThe load-bearing aprons — this is what the mattress actually rests on. | 3 each |
| Pocket-hole screws, 1-1/4" and 2-1/2" | 150 each |
| Wood glue | 6 oz |
| Mattress slats or bunkie boardCut slats from scrap 1x stock spaced per your mattress maker's guidance, or buy a bunkie board. | 1 each |
Overall cost: $$. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| Rectangle sides (grid)1x2 | 24 | 3/4" × 1 1/2" × 12" |
| Rectangle-to-rectangle joiners1x2 | 9 | 3/4" × 1 1/2" × 5 1/2" |
| Rectangle end joiners1x2 | 6 | 3/4" × 1 1/2" × 4 1/4" |
| Rectangle tops and bottoms1x2 | 24 | 3/4" × 1 1/2" × 6 1/2" |
| Back top rail and cleats2x2 | 3 | 1 1/2" × 1 1/2" × 75" |
| Side aprons2x3 | 2 | 1 1/2" × 2 1/2" × 75" |
| Legs2x2 | 4 | 1 1/2" × 1 1/2" × 30" |
| Arm tops2x2 | 2 | 1 1/2" × 1 1/2" × 39" |
| Arm aprons2x3 | 2 | 1 1/2" × 2 1/2" × 39" |
Buy 15 boards at 8 ft.
3 boards
6 boards
6 boards
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
You are probably wondering why you'd start with the small rectangles instead of the leg frames. Because once a rectangle is boxed in on both sides by its neighbors, you can no longer get a drill in to add pocket holes to it. So batch-cut all 24 sides, 24 tops/bottoms, 9 rectangle joiners, and 6 end joiners now, and drill pocket holes (set for 3/4" stock) into every joiner and top/bottom piece before you assemble a single rectangle.
Build nine "H"-shaped frames: two side pieces joined by a center joiner, using pocket screws and glue set for 1-1/2" stock. Build all nine to the same reference so they end up genuinely identical — any variance here shows immediately once they're side by side.
Add the tops and bottoms to each H-frame to close out the rectangle shape, then join three rectangles end to end into a column using the end joiners. Work on a flat, level surface and check each rectangle for square as you close it — small errors compound fast across three joined frames.
Build two H-shaped end frames from the 2x2 legs and 2x3 side aprons — these carry the actual load of the bed and mattress, so pocket-screw and glue every joint solidly.
Screw the three rectangle columns to the tops and bottoms of the leg-and-apron frames, closing the daybed into its final rectangular footprint. Confirm square across the whole frame with a diagonal tape measurement before locking everything down.
Build two more small frames from the arm tops and arm aprons — these become the raised side arms of the daybed. If you're using pocket holes, mirror the two so the visible screw holes land on the outside faces of both arms, not facing into the bed.
Fasten the mattress-support cleats to the inside faces of the side aprons, flush to the bottom, with 2-1/2" screws and glue. Rest slats across them, spaced per your mattress recommendation, or drop in a bunkie board.
Sand every rectangle edge and every apron and arm — there are a lot of exposed corners in this design and all of them get touched. If this bed will see everyday use rather than occasional lounging, consider reinforcing the rectangle-column-to-leg-frame joints with extra screws; it's a lighter structure than a solid-panel daybed.
