This is a straightforward grid bookshelf — a top, two sides, one center shelf, and vertical dividers splitting it into six equal cubbies — with a detail that keeps a piece this size from racking: 1x2 trim strips nailed and glued across the front and back, tying the whole frame together after the main joints are set. Attach that trim after the basic box and dividers are assembled and square, not before, since it's meant to lock the shape in rather than help build it.
Where the vertical dividers meet the shelves, apply glue on top of your screws — that's the joint doing the most work in the whole piece, since it's what keeps the shelf spans from sagging once loaded with books.
| Item | Qty |
|---|---|
| Pine, 1x12, 12 ft | 1 each |
| Pine, 1x12, 8 ft | 1 each |
| Pine, 1x2, 8 ft | 5 each |
| 2" self-tapping wood screws or pocket hole screws | 1 box |
| Brad nails, 1-1/4" and 3/4" | 1 box |
| Wood glue | 4 oz |
| Wood filler and finish | 1 each |
Overall cost: $$. Lumber prices vary by region, species, and season, so we give a band rather than a figure we would only be pretending to know.
| Part | Qty | T × W × L |
|---|---|---|
| TopPine 1x12 | 1 | 3/4" × 11 1/4" × 40 1/2" |
| SidesPine 1x12 | 2 | 3/4" × 11 1/4" × 26 3/4" |
| ShelvesPine 1x12 | 2 | 3/4" × 11 1/4" × 39" |
| Cubby dividersPine 1x12 | 4 | 3/4" × 11 1/4" × 12 1/4" |
| LegsPine 1x2 | 4 | 3/4" × 1 1/2" × 31" |
| Front/back trimPine 1x2Measure and cut to fit — lengths will vary slightly. | 6 | 3/4" × 1 1/2" × 37 1/2" |
Buy 8 boards at 8 ft.
3 boards
5 boards
Assumes 8 ft stock, a 1/8" saw kerf, and buying each part at its own width. Change the board size or kerf on the full board plan →
Mark out all your joint locations on the cut pieces. Predrill and countersink for 2" screws and glue throughout, or use a pocket-hole jig with 1-1/4" pocket hole screws instead.
Attach the bottom shelf's divider pieces to the bottom shelf with 2" screws. Attach the bottom shelf to the sides, applying glue at every point where a vertical cubby divider will line up — a 1x2 leg will reinforce this joint in a later step, but the glue here is what carries the shelf load long-term.
Attach the legs to the sides, flush on all sides, with 1-1/4" brad nails and wood glue.
Measure and cut the horizontal trim pieces to fit the front of the bookshelf, then repeat for the back. This trim ties the whole box together and is what keeps it from racking.
Attach the back trim with 3/4" brad nails and glue. Sand, fill nail holes, and finish.
